SD23456 2-6mm SCREW DRILLS (SET-5)
Rp2.051.000
Solid Carbide Screw Drill Set Set
Solid Carbide Screw Drill Set
Contents: SD2, SD3, SD4, SD5 and SD6
Out of stock
SKU : KEN1541100K
Solid Carbide Screw Drill Set Set
Solid Carbide Screw Drill Set
Contents: SD2, SD3, SD4, SD5 and SD6
Specification :
Brand : Kennedy Industrial
Contents : SD2, SD3,SD4,SD5 & SD6
eCl@ss Code : 21010101
No. of Pieces : 5
UNSPSC Code : 23241605
Weight per set : 80g
| Weight | 1 kg |
|---|
