PSSNR 3232P19 EXTERNAL TOOLHOLDER
Indexa Lever Lock External Toolholders – PSSN R/L
45° offset approach for negative square inserts.
Out of stock
SKUÂ :Â IND1063660K
Indexa Lever Lock External Toolholders – PSSN R/L
45° offset approach for negative square inserts.
Specification :
Brand : Indexa
Designation PSSN…. : R 3232P
Dimensions a : 12.5
Dimensions b : 32
Dimensions f : 40
Dimensions h=h1Â :Â 32
Dimensions l1Â :Â 170
Dimensions l2Â :Â 42
eCl@ss Code : 28039190
Overall Weight : 1.38
Supplier Part No. : 106-3660
UNSPSC Code : 23242106
