M2x0.4 WHITE 371 HSS-EV NIT THROUGH TAP
HSS âWhite Ringâ Taps
Manufactured to DIN 371/376
Suitable for the following Material Groups
Straight Flute – HSS-EV Nitride Finish
For through holes. Taper lead to
DIN form D (taper) (3.5 x P to 5 x P).
Tapping tolerance to 6HX.
Out of stock
SKU : SWT1853503W
HSS âWhite Ringâ Taps
Manufactured to DIN 371/376
Suitable for the following Material Groups
Straight Flute – HSS-EV Nitride Finish
For through holes. Taper lead to
DIN form D (taper) (3.5 x P to 5 x P).
Tapping tolerance to 6HX.
Specification :
Brand : Swiss Tech
eCl@ss Code : 21010210
Overall Length (mm) : 45.0
Shank Diameter (mm) : 2.8
Size – Pitch (mm) : M2.0 x 0.40
Square A/F : 2.1
Thread Length : 8.0
UNSPSC Code : 27112806
Weight each : 4g
| Weight | 1 kg |
|---|
