3/4″x14 BSPF HSS GT STR. FLUTE TAP SET
Rp2.916.000
Sets of Three
1 each, taper, second and plug lead.
Out of stock
SKU : SHR0852060D
Sets of Three
1 each, taper, second and plug lead.
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length (mm) : 28.0
Overall Weight : 0.765
Shank Diameter (mm) : 20.0
Size – Pitch : 3/4″ x 14
Supplier Part No. : –
Thread Length (mm) : 28.0
UNSPSC Code : 27112806
| Weight | 1 kg |
|---|
