12.7×12.7mm INVERTED CONE C/B BURR CUT 9
York Carbide Burrs – Inverted Cone
Inverted Cone
All sizes are nominal. Sizes marked * are 3mm shank, all others are 6mm shank.
Cut Numbers:
Cut 9 – Chipbreaker
Chipbreaker fast stock removal for improved control and reduced chips for use on hard materials, i.e. steel alloy 50RC, 60RC, carbon and cast iron.
Out of stock
SKU : YRK2109329K
York Carbide Burrs – Inverted Cone
Inverted Cone
All sizes are nominal. Sizes marked * are 3mm shank, all others are 6mm shank.
Cut Numbers:
Cut 9 – Chipbreaker
Chipbreaker fast stock removal for improved control and reduced chips for use on hard materials, i.e. steel alloy 50RC, 60RC, carbon and cast iron.
Specification :
Brand : York Abrasives
Cut No. : 9
eCl@ss Code : 21010101
Head Size Dia. x L (mm) : 12.7 x 12.7
UNSPSC Code : 23251706
| Weight | 1 kg |
|---|
