1/4″x19 BSPT HSS GT STR. FLUTE PLUG TAP
Rp373.000
BSPT (British Standard Pipe Taper) HSS Ground Thread Taps
IS0 529 – Straight Flute – Plug
Out of stock
SKU : SHR0852210C
BSPT (British Standard Pipe Taper) HSS Ground Thread Taps
IS0 529 – Straight Flute – Plug
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length (mm) : 67.0
Shank Diameter (inch) : 10.0
Size – Pitch : 1/4″ x 19
Supplier Part No. : –
Thread Length (mm) : 19.0
UNSPSC Code : 27112806
Weight each : 50g
| Weight | 1 kg |
|---|
