1/2″x14 BSPTx2″ O/D HSS DIE
Rp944.000
BSPTâ(British Standard Pipe Taper) HSS Ground Thread Dies
ISO 2284
For use in diestocks to produce external screw threads.
Out of stock
SKU : SHR0869230K
BSPTâ(British Standard Pipe Taper) HSS Ground Thread Dies
ISO 2284
For use in diestocks to produce external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Outside Diameter (inch) : 2″
Size – Pitch : 1/2″ x 14
Thickness (inch) : 5/8″
UNSPSC Code : 27112805
Weight each : 175g
| Weight | 1 kg |
|---|
