No.2BA HSS GT STR. FLUTE TAP SET
Sets of Three
1 each, taper, second and plug lead.
Out of stock
SKU : SHR0851820D
Sets of Three
1 each, taper, second and plug lead.
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Shank Diameter (mm) : 5.00
Size – Pitch : No.2 x 0.0319
Supplier Part No. : –
UNSPSC Code : 27112806
Weight per set : 27g
| Weight | 1 kg |
|---|
