M8x1.25 WHITE 371 HSS-EV NIT BLIND TAP
HSS âWhite Ringâ Taps
Straight Flute – HSS-EV Nitride Finish
For blind holes. Plug/bottoming lead to
DIN form C (2 x P to 3 x P).
Tapping tolerance to 6HX.
Out of stock
SKU : SWT1854027W
HSS âWhite Ringâ Taps
Straight Flute – HSS-EV Nitride Finish
For blind holes. Plug/bottoming lead to
DIN form C (2 x P to 3 x P).
Tapping tolerance to 6HX.
Specification :
Brand : Swiss Tech
eCl@ss Code : 21010210
Overall Length (mm) : 90.0
Shank Diameter (mm) : 8.0
Size – Pitch (mm) : M8.0 x 1.25
Square A/F : 6.2
Thread Length : 20.0
UNSPSC Code : 27112806
Weight each : 32g
| Weight | 1 kg |
|---|
