3/8″x19 BSPF HSS GT SPIRAL POINT TAP
Rp1.123.000
BSP(F) (British Standard Pipe Fittings) HSS Ground Thread Taps
IS0 529 – Spiral Point/Gun Nose
Out of stock
SKU : SHR0852030E
BSP(F) (British Standard Pipe Fittings) HSS Ground Thread Taps
IS0 529 – Spiral Point/Gun Nose
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Shank Diameter (mm) : 12.5
Size – Pitch : 3/8″ x 19
Square A/F : 10.0
UNSPSC Code : 27112806
Weight each : 85g
| Weight | 1 kg |
|---|
