3/4″x14 NPT HSS GT STR. FLUTE PLUG TAP
Rp1.587.000
NPTF (National Pipe Taper Fuel) HSS Ground Thread Taps
ANSIâ94.9
Straight Flute
Out of stock
SKU : SHR0853060C
NPTF (National Pipe Taper Fuel) HSS Ground Thread Taps
ANSIâ94.9
Straight Flute
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length (inch) : 3 1/4″
Shank Diameter : 0.906
Shank Diameter : 1.312 mm
Size – Pitch : 3/4″ – 14
Supplier Part No. : –
Thread Length (inch) : 1 3/8″
UNSPSC Code : 27112806
Weight each : 230g
Weight each : 668g g
| Weight | 1 kg |
|---|
