1″x8 BSW HSS GT STR. FLUTE TAPER TAP
BSW (British Standard Whitworth) HSS Ground Thread Taps
ISO 529 – Straight Flute Individual Sizes
Out of stock
SKU : SHR0851450A
BSW (British Standard Whitworth) HSS Ground Thread Taps
ISO 529 – Straight Flute Individual Sizes
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length : 130.0
Shank Diameter : 18.00
Size – Pitch : 1″ x 8
Thread Length : 45.0
UNSPSC Code : 27112806
Weight each : 269g
| Weight | 1 kg |
|---|
