1″x11 BSPF HSS GT STR. FLUTE TAP SET
Rp4.327.000
Sets of Three
1 each, taper, second and plug lead.
Out of stock
SKUÂ :Â SHR0852080D
Sets of Three
1 each, taper, second and plug lead.
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length (mm)Â :Â 33.0
Overall Weight : 0.425
Shank Diameter (mm)Â :Â 25.0
Size – Pitch : 1″ x 11
Thread Length (mm)Â :Â 33.0
UNSPSC Code : 27112806
| Weight | 1 kg |
|---|
