1/8×28 BSPTx1″ O/D HSS DIE
Rp474.000
BSPT (British Standard Pipe Taper) HSS Ground Thread Dies
ISO 2284
For use in diestocks to produce external screw threads.
Out of stock
SKU : SHR0869150K
BSPT (British Standard Pipe Taper) HSS Ground Thread Dies
ISO 2284
For use in diestocks to produce external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Outside Diameter (inch) : 1″
Size – Pitch : 1/8″ x 28
Thickness (inch) : 3/8″
UNSPSC Code : 27112805
Weight each : 26g
| Weight | 1 kg |
|---|
