1/8″x28 BSP YELLOW RING SP/PT DIN 5156 HSS-EV TAP
BSP – British Standard Pipe
DIN 5156
Out of stock
SKU : SWT1850902Y
BSP – British Standard Pipe
DIN 5156
Specification :
Brand : Swiss Tech
eCl@ss Code : 21010210
Overall Length (mm) : 90.0
Shank Diameter (mm) : 7.0
Size – Pitch : 1/8″ x 28
Square Size : 5.5
Thread Length (mm) : 20.0
UNSPSC Code : 27112806
Weight each : 16g
| Weight | 1 kg |
|---|
