1/4″x20 BSWx1″ O/D HSS DIE
Sherwood BSW (British Standard Whitworth) HSS Ground Thread Dies
BS 1127
For use in diestocks to produce external screw threads.
Out of stock
SKU : SHR0865730K
Sherwood BSW (British Standard Whitworth) HSS Ground Thread Dies
BS 1127
For use in diestocks to produce external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Outside Diameter (inch) : 1″
Overall Weight : 0.025
Size – Pitch : 1/4″ x 20
Thickness (inch) : 3/8″
UNSPSC Code : 27112805
Weight each : 27g
