1/4×19 BSPTx1.5/16 O/D HSS DIE
Rp647.000
BSPTâ(British Standard Pipe Taper) HSS Ground Thread Dies
ISO 2284
For use in diestocks to produce external screw threads.
Out of stock
SKU : SHR0869170K
BSPTâ(British Standard Pipe Taper) HSS Ground Thread Dies
ISO 2284
For use in diestocks to produce external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Outside Diameter (inch) : 1 5/16″
Size – Pitch : 1/4″ x 19
Thickness (inch) : 7/16″
UNSPSC Code : 27112805
Weight each : 62g
| Weight | 1 kg |
|---|
