1/4″x19 BSP YELLOW RING SP/PT DIN 5156 HSS-EV TAP
BSP – British Standard Pipe
DIN 5156
Out of stock
SKU : SWT1850904Y
BSP – British Standard Pipe
DIN 5156
Specification :
Brand : Swiss Tech
eCl@ss Code : 21010210
Overall Length (mm) : 100.0
Shank Diameter (mm) : 11.0
Size – Pitch : 1/4″ x 19
Square Size : 9.0
Thread Length (mm) : 22.0
UNSPSC Code : 27112806
Weight each : 48g
| Weight | 1 kg |
|---|
