1/4″x18 NPT HSS HEXAGON DIE NUT
NPT (National Pipe Taper) HSS Ground Thread Die Nuts
For use with spanners to clean and repair existing external screw threads.
SKU : SHR0869580K
NPT (National Pipe Taper) HSS Ground Thread Die Nuts
For use with spanners to clean and repair existing external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Size – Pitch : 1/4″ x 18
Thickness (inch) : 1/2″
UNSPSC Code : 27112805
Weight each : 51g
Width : 1.10″
| Weight | 1 kg |
|---|
