1/2″x14 NPT HSS HEXAGON DIE NUT
NPT (National Pipe Taper) HSS Ground Thread Die Nuts
For use with spanners to clean and repair existing external screw threads.
Out of stock
SKU : SHR0869600K
NPT (National Pipe Taper) HSS Ground Thread Die Nuts
For use with spanners to clean and repair existing external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Size – Pitch : 1/2″ x 14
Thickness (inch) : 13/16″
UNSPSC Code : 27112805
Weight each : 147g
Width : 1.67″
| Weight | 1 kg |
|---|
