1/2″x14 BSPT HSS GT STR. FLUTE PLUG TAP
Rp835.000
BSPT (British Standard Pipe Taper) HSS Ground Thread Taps
IS0 529 – Straight Flute – Plug
Out of stock
SKU : SHR0852230C
BSPT (British Standard Pipe Taper) HSS Ground Thread Taps
IS0 529 – Straight Flute – Plug
Specification :
Brand : Sherwood
eCl@ss Code : 21010210
Overall Length (mm) : 87.0
Shank Diameter (inch) : 16.0
Size – Pitch : 1/2″ x 14
Thread Length (mm) : 26.0
UNSPSC Code : 27112806
Weight each : 142g
| Weight | 1 kg |
|---|
