1/2″x14 BSPT HSS HEXAGONDIE NUT
BSPT (British Standard Pipe Taper)
HSS Ground Thread Die Nuts
BS 1127
For use with spanners to clean and repair existing external screw threads.
Out of stock
SKU : SHR0869330K
BSPT (British Standard Pipe Taper)
HSS Ground Thread Die Nuts
BS 1127
For use with spanners to clean and repair existing external screw threads.
Specification :
Brand : Sherwood
eCl@ss Code : 21010200
Outside Diameter (inch) : 1.67″
Size – Pitch : 1/2″ x 14
Thickness (inch) : 13/16″
UNSPSC Code : 27112805
Weight each : 142g
| Weight | 1 kg |
|---|
