1/2″x14 BSP YELLOW RING SP/FL DIN 5156 HSS-EV TAP
BSP – British Standard Pipe Bright Finish
DIN 5156
Out of stock
SKU : SWT1850938Y
BSP – British Standard Pipe Bright Finish
DIN 5156
Specification :
Brand : Swiss Tech
eCl@ss Code : 21010210
Overall Length (mm) : 125.0
Shank Diameter (mm) : 16.0
Size – Pitch : 1/2″ x 14
Square Size : 12.0
Thread Length (mm) : 25.0
UNSPSC Code : 27112806
Weight each : 152g
| Weight | 1 kg |
|---|
